15
14. Identify the Right Inner Base Cover (91). Slide
the Right Inner Base Cover onto the Upright
Base (94), under the Upright Wire (82), as
shown in the inset drawing. Make sure that the
Upright Wire is in the notch (Q) in the Right
Inner Base Cover as shown.
Then, slide the Right Base Cover (90) downward
onto the Right Inner Base Cover (91).
Repeat this step on the left side of the tread-
mill with the Left Inner Base Cover (not
shown) and the Left Base Cover (not shown).
Note: There is not a wire on the left side of the
treadmill.
14
82
94
91
90
85
Q
91
Q
82
15. Make sure that all parts are properly tightened before you use the treadmill. If there are sheets of plastic
on the treadmill decals, remove the plastic. To protect the floor or carpet, place a mat under the treadmill. To
avoid damage to the console, keep the treadmill out of direct sunlight. Keep the included tools in a secure
place; one or more of the tools may be needed to make adjustments to the treadmill in the future. Note: Extra
hardware may be included.
