ADJUSTING THE HACK SQUAT ARM
To adjust the height of the Hack Squat Arm (9), stand
with your shoulders under the Shoulder Pads (13,
14). Squeeze the Release Handle (22) and move the
Arm to the desired position. Let go of the Release
Handle and allow the Backrest Adjustment Pin (not
shown) to engage the Adjustment Bar (not shown).
This section explains how to adjust the weight system. Make sure all parts are properly tightened each time the
weight system is used. Replace any worn parts immediately. The weight system can be cleaned with a damp cloth
and a mild, non-abrasive detergent. Do not use solvents.
12
ADJUSTMENTS
13
12
22
9
14
STORING THE HACK SQUAT FOOT PLATE
To store the Hack Squat Foot Plate (3), pull the
Adjustment Pin Assembly (25) and lift on the Foot
Plate. Reengage the Pin into the Foot Plate.
25
3
WARNING:Do not lower the Hack
Squat Arm (9) to a position that causes the
lower back to move away from the Hack Squat
Backrest (12).
