9
4. Identify the Left and Right Base Covers (73, 74).
Slide the Left and Right Base Covers onto the
Left and Right Uprights (75, 76) as shown.
74
76
75
73
4
5. Identify the Left Handrail (71). If there is a wire in
the Left Handrail, remove and discard it.
Hold the Left Handrail (71) near the Left Upright
(75). Insert the wire tie on the Upright Wire (70)
through the bottom and pull it out of the end
of the Left Handrail as shown. Then, pull the
Upright Wire through the Left Handrail.
Attach the Left Handrail (71) to the Left Upright
(75) with two 3/8" x 3 1/2" Screws (9) and two
3/8" Star Washers (5). Make sure not to pinch
the Upright Wire (70). Start both Screws, but
do not tighten them yet.
9
5
71
75
Wire
Tie
70
5
To Next Page
