Nordson 3100 User Manual

Overview
A 2-11
E 2000 Nordson Corporation
All rights reserved
41-3000
Issued 11/00
A2EN-02-[3-OVER]–2
Model
Pump
Manifold
Control
Options
Voltage
Elec. cap.
– /
Model Description Tank Capacity
Melt Rate
3100 Series 3100 3.6 kg (8 lb) 3.6 kg/hr (8 lb/hr)
3400 Series 3400 5.4 kg (12 lb) 6.8 kg/hr (15 lb/hr)
3500 Series 3500 8.6 kg (19 lb) 9.5 kg/hr (21 lb/hr)
3700 Series 3700 13.6 kg (30 lb) 18.1 kg/hr (40 lb/hr)
3830 Series 3830 13.6 kg (30 lb) 15.9 kg/hr (35 lb/hr)
3860 Series 3860 31.8 kg (70 lb) 24.9 kg/hr (55 lb/hr)
3890 Series 3890 45.4 kg (100 lb) 24.9 kg/hr (55 lb/hr)
3930 Series 3930 13.6 kg (30 lb) 27.3 kg/hr (60 lb/hr)
3960 Series 3960 31.8 kg (70 lb) 45.5 kg/hr (100 lb/hr)
AG-30 AquaGuard 8.6 kg (19 lb) 9.5 kg/hr (21 lb/hr)
Voltage Description
1 200-240 VAC without neutral
2 400/230 VAC with neutral
3 400 VAC without neutral
Pump Description
E 14:1 SP piston pump
F 21:1 SP piston pump
G 6:1 SP piston pump
K AC gear pump, 200 VAC
L AC gear pump, 230 VAC (when Voltage = 1)
L AC gear pump, 250 VAC (when Voltage = 2)
O DC gear pump, 49 kg/hr (108 lb/hr)
R DC gear pump, 24.5 kg/hr (54 lb/hr)
S DC gear pump, 11 kg/hr (24 lb/hr)
T DC gear pump, 24.5 kg/hr (54 lb/hr)
U DC gear pump, 3.6 kg/hr (8 lb/hr)
W DC gear pump, 1.8 kg/hr (4 lb/hr)

Nordson 3100 Specifications

General

Brand	Nordson
Model	3100
Category	Melting Machines
Language	English
