page 12 off 20
H
14
Motor cover
15
color
code ring
16 M12 connector
17 M12 screw nut
complete the second pump
. Make
sure you know which is A and which is
B
H
38 A
dapt
e
r
I
Now assemble the upper parts.
Make sure the M12 connector (16)
does not turn to avoid the wires
from tossing!
The color code ring (15) has no
function but to show the aCCura
size.
Orange = aCCura 1
Blue = aCCura 2
Green = aCCura 3
White = aCCura 4
Black = aCCura 2 anaerob (full
plastic)
If available:
Attach the adaptor (38) to the pump
housing (9) by means of 4 x M2 x 8
screws (39)
Do not forget the seal (40)
9 Pump housing
9 Pump housing
38 A
dapt
e
r
J
J

Nordson ASYMTEK Specifications

General

Fluid Types	Adhesives, underfills
Dispensing Technologies	Jet, needle
Work Area	Varies by model
Vision System	High-resolution cameras for alignment and inspection
Applications	Underfill, encapsulation, solder paste dispensing, adhesive dispensing
Material Compatibility	Compatible with a wide range of materials, including those with high viscosity or abrasive properties
