1.1 Use compliance
Before operation, please carefully read the following
1. Please intensively study this manual before commissioning. Do get familiar with the
operation manual before each start of the pump or every time when the operator changes.
2. Please note, that this manual is part of this particular pump even when being moved to
another department or company.
3. The pump may only be used by healthy people
4. Do only use ASYMTEK spare parts. Damages caused by using other parts are not
supported by the ASYMTEK warranty.
5. Should any of this manual not be clear or understandable, please do contact your
distributor or write ASYMTEK.com.
This pump is a self-priming endless dosing pump. Following materials may be used with it for
metering or transferring:
• Adhesives and sealants with or without spheres
• Material resistant fluids and pastes
• Oils and lubricants
• Paints and lacquers
Do not use with cyanoacrylates, anaerobic glues or any explosion rated nor poisonous
products. Please do contact your distributor for further information. We are not chemical
specialists so please do check the pump material resistance of all wetted parts with your
product supplier. Any improper use will produce the loss of the support of the ASYMTEK
warranty.
Explicit compliance for the pumped material:
Depending on the application, the maximum temperature may not succeed 120°C. With the
use of aggressive products, please do always contact your distributor and product supplier to
get approval before operation and or commissioning.
Make sure, that the local legislation has been incorporated all safety relevant demands are
being kept.
Changes done by the user result in loss of warranty. All damage claims upon will be ignored.
All safety relevant technical issues lose the ASYMTEK warranty support.
All rights reserved. This manual may not be duplicated without written agreement of the manufacturer.
This sign shows a safety relevant message. Make sure all
operator personnel and safety people take note or have been
made aware.

Nordson ASYMTEK Specifications

General

Fluid Types	Adhesives, underfills
Dispensing Technologies	Jet, needle
Work Area	Varies by model
Vision System	High-resolution cameras for alignment and inspection
Applications	Underfill, encapsulation, solder paste dispensing, adhesive dispensing
Material Compatibility	Compatible with a wide range of materials, including those with high viscosity or abrasive properties
