Nordson DuraBlue D16L - No Hot Melt Output from One or more Applicators; Durablue Troubleshooting Charts

Troubleshooting
6-13
Part 1073401_07
E 2021 Nordson Corporation
+
−
No hot melt output from one or more applicators
Go to
T.3
+
−
+
−
Do dashes appear in both
the left and right display?
Turn the control switch on.
Does the melter start?
Stop.
+
−
Upload new software.
Refer to Appendix C.
+
−
Do the words UP LOAD
appear across the
displays?
Is the wire harness that is
connected to terminal X7
on the main board loose?
Turn the control switch off,
secure the harness to
terminal X7, and then turn
the control switch back on
+
−
Is the fault LED
illuminated?
Replace the control switch.
P/N 1017947.
Has glue output stopped
from all applicators?
+
−
Is the ready LED
illuminated?
+
−
Is the control panel
illuminated?
Go to
T.1
Go to
T.5
Go to
T.4
DuraBlue
Troubleshooting
Charts
Start
Go to
T.2
