Parts
7-17
Part 1073401_07
E 2021 Nordson Corporation
Item Part Description Quantity Note
— 1031216
Service kit, drive assembly,
1
/
6
hp, 600 psi,
non-filtered
—
— 1031217
Service kit, drive assembly,
1
/
6
hp, 1100 psi, filtered
—
— 1031218
Service kit, drive assembly,
1
/
4
hp, 600 psi,
non-filtered
—
— 1031219
Service kit, drive assembly,
1
/
4
hp, 1100 psi, filtered
—
1 ‐ ‐ ‐ ‐ ‐ ‐ S Pump 1 A
2 ‐ ‐ ‐ ‐ ‐ ‐ S Manifold 1 B
3 ‐ ‐ ‐ ‐ ‐ ‐ S Motor 1 C
4 ‐ ‐ ‐ ‐ ‐ ‐ S Coupling, drive,
5
/
8
x
5
/
8
(
1
/
6
hp drive) 1 D
5 ‐ ‐ ‐ ‐ ‐ ‐ S O-ring, -118, Viton, 0.862 x 0.103 in. 1
6 ‐ ‐ ‐ ‐ ‐ ‐ S O-ring, Viton, 1.188 x 1.388 x 0.094 in. 1 A
7 ‐ ‐ ‐ ‐ ‐ ‐ S O-ring, Viton, 0.750 x 0.938 x 0.094 in. 1 A
8 ‐ ‐ ‐ ‐ ‐ ‐ S Key, machine,
3
/
16
x 1 inch long 1 D
9 ‐ ‐ ‐ ‐ ‐ ‐ S Screw, hex, cap, M8 x 90, 304 stainless-steel 2 A
10 ‐ ‐ ‐ ‐ ‐ ‐ S Washer, flat, narrow, M8 2 A
11 ‐ ‐ ‐ ‐ ‐ ‐ S Screw, hex, cap, M6 x 25 4
12 ‐ ‐ ‐ ‐ ‐ ‐ S Washer, lock, split, M6 4
13 ‐ ‐ ‐ ‐ ‐ ‐ S Bracket, pump support 1
NS ‐ ‐ ‐ ‐ ‐ ‐ S Capacitor 1 C
NS ‐ ‐ ‐ ‐ ‐ ‐ S Grease, high-temperature, 0.50 oz 1
— 1043467
Service kit, motor coupling, gerotor
—
4 ‐ ‐ ‐ ‐ ‐ ‐ S Coupling, drive,
5
/
8
x
5
/
8
in. 1
8 ‐ ‐ ‐ ‐ ‐ ‐ S Key, machine, drive, 0.1875 x 0.70 in. 1
NOTE A: Provided in pump service kit. Refer to Pump earlier in this section for kit part numbers.
B: Refer to Manifold earlier in this section.
C: Refer to Motor earlier in this section.
D: Provided in the motor coupling service kit.
NS: Not Shown
