SYSTEM CONTROLLER FUNCTION CODES AND VALVES
Code Function Name Function Value Code Function Name Function Value
F00 Gun Type 00= Encore XT/HD
02= Robot
F18 Pump Type 00= Venturi
01= HDLV
02= COD
F01 Fluidizing 00= Hopper
01= Box
02= Disable
F19 Control Type 00= Local
01= External
F02 Display Units 00= SCFM
01= M3/HR
F20 Gun Number
*See manual for additional values
F21 Maintenance Timer,
Pump
00= View
01= Set
02= Reset
*See manual for additional values
F03 Electrostatic Control 00= Custom
01= Classic
F04 Powder Flow Control
F22 Purge
*See manual for additional values
F05 Keypad Lockout 00= Unlocked
04= Reset Password
*See manual for additional values
F25 Pattern Air Delay 0.00-5.00
F26 Soft Siphon 1-10 Sec
F06 Vibratory Box Delay O 00-90 Seconds
F27 Soft Gun 1-10 Sec
F07 Maintenance Timer,
Gun
*See manual for additional values
F28 Pulse ON 0.1-0.95 Sec
F08 Setting Trigger Func-
tion
*See manual for additional values
F29 Pulse OFF 0.1-0.95 Sec
F09 Help Codes 00= Enable
01= Disable
F30 Siphon Pulses 1-99
F31 Gun Pulses 1-99
F10 Zero Reset (Flow)
*See manual for additional values
F32 Powder Pre-Load
*See manual for additional values
F11 Gun Display Errors 00= Flash
01= O
F33 Manifold Purge 0-10 Sec
F12 uA Lower Limit
*See manual for additional values
F34 Conveyance Air
Constant A
*Constant should match sticker
on manifold
F13 uA Upper Limit
*See manual for additional values
F35 Conveyance Air
Constant C
*Constant should match sticker
on manifold
F14 Total Hours 00= Gun Total Hours
01= Pump Total Hours
F36 Pattern Air Constant A
*Constant should match sticker
on manifold
F15 Save/Restore/Reset 00= Save
01= Restore
02= Reset
F37 Pattern Air Constant C
*Constant should match sticker
on manifold
F16 Gun Display Brightness 00= Low
01= Medium
02= Maximum
F17 Number of Presets
*See manual for additional values
