Nordson FP-200 Instruction Sheet

Converting an FP-200 Extrusion Gun to an FP-200 Swirl Gun
13
Part 237494_02
E 2012 Nordson Corporation
Conversion Kit and Accessories
Table 1 lists the FP-200 conversion kit part number (P/N) and the part
numbers for the parts contained in the kit. It also lists the part numbers for
the extrusion gun heat shield and for Loctite, which is an anaerobic sealant.
Table 1 FP-200 Gun Conversion Kit and Accessories
Part Description Quantity Note
303 028
Kit, Extrusion to Swirl, FP-200 Gun
– A, B
234 894
S Fitting, #10–32, T, Manifold
1
220 643
S Connector, Male, 1/8 in. x 1/8 in.
1
981 056
S Screw, Socket #8–32 x 0.750 in.
2
983 011
S Washer, Lock, Internal, #8
2
234 964
S Manifold, Air, FP-200
1
234 880
S Tube, Manifold, FP-200
1
101 887
S Clamp, Tube 0.228 in.
1
234 969
S Tube, Manifold Assembly
1
234 882
S Regulator, Air, Miniature
1
157 266
S Module, CF-200, Wide Pattern
1
234 965
Shield, Heat, FP-200, Swirl
1
174 885
Loctite 222, low strength, 0.5 ml
–
NOTE A: This kit converts P/N 234 897 to P/N 234 896. Order the heat shield (P/N 234 965) separately.
B: Order nozzles separately. Refer to Table 2.
