Nordson FP-200 Instruction Sheet

Converting an FP-200 Extrusion Gun to an FP-200 Swirl Gun
14
Part 237494_02
E 2012 Nordson Corporation
Nozzles
The FP-200 swirl gun accommodates a variety of swirl nozzles. Table 2 lists
the part numbers for nozzles commonly used with the FP-200 swirl gun.
Table 2 Nozzles Commonly Used with the FP-200 Swirl Gun
Nozzle Type
P/N Orifice Diameter Notes
Wide pattern
swirl nozzles
125 607 0.64 mm (0.025 in.) One-piece nozzle and
nut assembly
Use with CF-200 wide
pattern module
(P/N 157 266)
131 998 0.76 mm (0.030 in.)
131 635 1.17 mm (0.046 in.)
Swirl nozzles 104 100 0.20 mm (0.008 in.) Use with CS-WF
nozzle retaining nut
(P/N 119 202)
Use with CF-200 wide
pattern module
(P/N 157 266)
104 101 0.25 mm (0.010 in.)
860 548 0.31 mm (0.012 in.)
860 574 0.36 mm (0.014 in.)
860 575 0.41 mm (0.016 in.)
860 226 0.46 mm (0.018 in.)
860 435 0.51 mm (0.020 in.)
100 728 0.64 mm (0.025 in.)
810 381 0.76 mm (0.030 in.)
810 382 1.02 mm (0.040 in.)
810 300 1.27 mm (0.050 in.)
Issued 10/12
Original copyright date 1997. Nordson and the Nordson logo are registered trademarks of Nordson Corporation.
Loctite is a registered trademark of Loctite Corporation.
