Nordyne JS6BD Series User Manual

11
Table 4. Electrical Specifi cations & Physical Data
Model No. JS6BD 24K 30K 36K 42K 48K 60K
Electrical
Data
Volts-Cycles-Phase 208/230-60-1
Total Amps 11.6 13 18.1 23.5 24.3 30.7
Delay Fuse Max. 20 25 25 35 35 40
Min. Circuit Ampacity 12.9 14.5 20.1 26.2 27.0 34.2
Component
Data
Coil
Area 8.3 8.3 13.3 15.3 15.3 17.8
Rows-FPI 1-22 1-22 1-22 1-16 1-16 1-16
Tube Dia. MC
Fan Motor
Type PSC
Amps 0.7 0.7 1.4 1.4 1.4 1.4
Watts-HP 0.1 0.1 0.25 0.25 0.25 0.25
Fan Blade
Dia. 18” 18” 18” 24” 24” 24”
# Blades 3 3 4 2 2 2
SCFM 2800 3000 3000 3500 3500 3800
Compressor Data
RLA 10.9 12.3 16.7 22.1 22.9 29.3
LRA 49 59 88 115 115 150
Refrigerant Suction Line: Length/O.D.
Liquid Line: All Lengths - 3/8”O.D.
15 - 24 ft. 3/4” 3/4” 3/4” 7/8” 7/8” 7/8”
25 - 39 ft. 3/4” 3/4” 7/8” 7/8” 7/8” 1-1/8”
40 - 75 ft. 3/4” 3/4” 7/8” 7/8” 7/8” 1-1/8”
R-410A Refrigerant Charge (in Ounces):
(Outdoor unit, Indoor Unit - 15’ Line Set)
78 80 89 88 110 115
Approximate Weight (lbs.)
Net 113 116 135 157 163 188
Ship 118 121 140 163 169 194
