Nordyne JS6BD Series User Manual

14
L1
L2
T1
T2
Compressor
Contacts
1. Disconnect all power before servicing.
2. For supply connections use copper conductors only.
3. Not suitable on systems that exceed 150 volts to ground.
4. For replacement wires use conductors suitable for 105˚ C.
5. For ampacities and overcurrent protection, see unit rating plate.
6. Connect to 24 vac/40va/class 2 circuit. See furnace/air handler installation
instructions for control circuit and optional relay/transformer kits.
7.
Single PhaseSplit System Air Conditioner (Outdoor Section)
Legend
Field Wiring
Factory Wiring:
Low Voltage
High Voltage
NOTES:
1. Couper le courant avant de faire letretien.
2. Employez uniquement des conducteurs en cuivre.
3. Ne convient pas aux installations de plus de 150 volt a la terre.
C
H
F
Dual
Capacitor
T1 T2
L1 L2
Contactor
(1 Phase)
Field Supply
L1 GrdL2
Grounding
Screw
C
R
S
C
R
S
See Note 6.
Red or Red Black
Red
Yellow
Black
Start
Capacitor
2
3
Start
Relay
1
Black
Blue
Orange
H
C
F
Dual Capacitor
C
R
S
Outdoor
Fan Motor
Compressor
C
R
S
24 Volt Field
Connections
CC - Contactor Coil
CCH - Crankcase Heater
HPS-High Pressure Switch
CC
CCH (Optional)
Black or
Black White
Yellow or
Yellow Black
Yellow
Outdoor
Fan Motor
Compressor
Crankcase
Heater
(Optional)
208/230V
ASCT
Anti-Short Cycle Timer (ASCT) may or may not be installed in the unit. If desired,
ASCT is factory installed on select models only or may be field installed as shown using
manufacturer's approved kit. If not present, connect Yellow and Black wires per Note 6.
ASCT
T2
T1
T3
Yellow
Black
(See
Note 7.)
ASCT
(See
Note 7.)
Black
Red
or
Yellow
HPS
HPS
T1
T2
T3
Figure 6. JS6BD Wiring Diagram (3.5 & 5 Ton Units)
7103880
