2.6 External View
Indoor Installation
Pressure Relief Valve
(Heating)
Drain Pipe
Intake Pipe
Exhaust Pipe
Operation Display
Water Drain Valve
(with Water Filter)
Water Drain Valve
(with Water Filter)
Heating Supply
Auto Feeder Shutoff Valve
Water Drain Valve
Heating Return
Auto Feeder Inlet
Gas Supply Valve
Water Drain Valve
Water Supply Valve
Hot Water Outlet (DHW)
Pressure Relief Valve (DHW)
Drain Pipe
Cold Water Inlet (DHW)
Water Drain Valve
(with Water Filter)
