1. Features and Product
Description
1.1 Features
• Flush Mount
• Indoor and Outdoor Use
• Keypad Programmable
• Self-Contained Single Door Access Control Functionality
• Illuminated Backlit Keys
• Keypress Feedback via Built-In Sounder
• Bi-Color Red/Green LED Indicates Relay Status
• Yellow LED Indicates Program Mode
• 120 Users
• 10 to 30 Volt DC Operation
• 12 to 24 Volt AC Operation
• 2AmpMainRelay
• Lock Release Output With Timer
• Alarm Zone Shunt Relay
• Propped Door Alarm Relay
• Forced Door Alarm Relay
• Remote Trigger Input (REX)
• 5-Year Warranty
1.2 Product Description
The model 232e Keypad is designed for security and is perfect for
self-contained access control applications.Itfeaturesoutputrelays
to release the door lock, to shunt an alarm zone, and to trigger both
a propped or forced door alert. Also, the 232e Keypad contains in-
puts for door monitor and REX. It allows up to 120 users.
All e style keypads are designed for both indoor and outdoor flush
mount applications. The electronics for each e keypad are conformal
coated in the manufacturing process in order to provide this level of
application flexibility. In addition, each e style keypad uses hard-
ened keys to assure long-term, high-quality performance. Each e
style keypad contains illuminated clear keys that make operation in
low-light situations easy and accurate. Installation is easy. All e style
keypads mount to any standard single-gang electrical box or directly
to any wall.
IEI 232e Standalone Installation/Programming Manual
2 Document # 6054004, Rev. 2.1
