AP technical specifications 129
Nortel WLAN Series 2332 Access Point Installation Guide
MAC addresses
Each Series 2332 access point is assigned a unique block of 64 MAC addresses. Each radio has 32 MAC addresses and
can therefore support up to 32 SSIDs, with one MAC address assigned to each SSID as its BSSID.
An AP’s MAC address block is listed on a label on the back of the AP. If the AP is already deployed and running on the
network, you can display the MAC address assignments by using the show {ap | dap} status command.
All MAC addresses on an AP are assigned based on the AP’s base MAC address, as described in Table 9 on page 129.
Table 8: 802.11b Radio Specifications
Specification Description
Antenna type Integrated omnidirectional with (2) radiating elements to allow for the use of
diversity
Antenna gain Internal: 3.86 dBi peak (Azimuth) and 2.48 dBi peak (Elevation)
Frequency band 2.4 GHz to 2.4835 GHz based on country regulations
Operating channels Based on the country of operation specified by the system administrator
Association rates 11 Mbps, 5.5 Mbps, 2 Mbps, and 1 Mbps, with automatic fallback
Modulation BPSK, QPSK, CCK
Transmit power Based on the country of operation specified by the system administrator
Table 9: 802.11g Radio Specifications
Specification Description
Antenna type Integrated omnidirectional with (2) radiating elements to allow for the use of
diversity
Antenna gain Internal: 3.86 dBi peak (Azimuth) and 2.48 dBi peak (Elevation)
Frequency band 2.4 GHz to 2.4835 GHz based on country regulations
Operating channels Based on the country of operation specified by the system administrator
Association rates 54 Mbps, 48 Mbps, 36 Mbps, 24 Mbps, 18 Mbps, 12 Mbps, 9 Mbps, and
6 Mbps, with automatic fallback
Modulation Orthogonal frequency division multiplexing (OFDM)
Transmit power Based on the country of operation specified by the system administrator
