External Antennas 63
Nortel WLAN Series 2332 Access Point Installation Guide
External antenna selector guide for the Series 2332 Access Points
for indoor operation
Warning! Intentional radiators, such as the Nortel WLAN Series 2332 Access
Points, are not intended to be operated with any antenna(s) other than those
furnished by Nortel. An intentional radiator may only be operated with the
antenna(s) with which it is authorized. For a complete listing of antennas for
use with this product, visit http://www.nortel.com/support.
Table 4: External Antenna Selector Guide for Series 2332 Access Points
Cushcraft
Nortel
Model
Number
WSS
Model
String
2.4 GHz Antennas
S2403BPXN36RSM DR4000088E6 24493 WLAN Collinear Omni-directional Dipole
Antenna contains two collocated elements with an
average gain of 4.9 dBi and a 3-foot cable with a
Reverse SMA connector. For use in Warehouses,
Auditoriums, Shopping Malls, industrial
complexes and more. It can be mounted either on a
pole or hung from a ceiling.
S2406PN36RSM DR4000075E6 24553 WLAN Directional Patch Panel Antenna with an
average gain of 6.5 dBi and a 3-foot cable with a
Reverse SMA connector. For use in Hallways or
corridors. Easy to disguise or hide.
SL2402PN36RSM DR4000074E6 24203 WLAN Omni-directional Patch Panel Ceiling
Mount Antenna with an average gain of 0.0 dBi
and a 3-foot cable with a Reverse SMA connector.
For use in contemporary in-building WLAN
applications.
SQ2405DDN36RSM DR4000073E6 24403 WLAN Bi-directional Patch Panel Ceiling Mount
Antenna with an average gain of 4.5 dBi and a
3-foot cable with a Reverse SMA connector. For
use in Offices, Shopping Complexes,
Transportation Terminals, Educational Campuses,
Hallways, and Tunnels.
S2409PN36RSM DR4000076E6 24883 WLAN Directional Patch Panel Array Antenna
with an average gain of 8.8 dBi and a 3-foot cable
with a Reverse SMA connector. For use where a
shaped pattern is needed to provide enhanced
coverage of deep rooms, warehouse bays, or any
elongated activity zone
