78 External Antennas
NN47250-307 (324136-A Version 01.03)
13 High-Gain Directional Panel Antenna
Nortel Order Number: DR4000090E6
❥ Cushcraft Model S4901790PN36RS
❥ 5.15 - 5.25 GHz, 15.7 dBi Peak Gain
❥ 5.25 - 5.35 GHz, 15.9 dBi Peak Gain
❥ 5.470 - 5.725 GHz, 16.0 dBi Peak Gain
❥ 5.725 - 5.85 GHz, 15.8 dBi Peak Gain
❥ Wall or pole mounting available for 1.5" to 3.5" diameter pole giving up to 15° of down-tilt
❥ Symmetrical and uniform 90 degree H-plane and 5.5 degree E-plane patterns
❥ Measures 2.74" in diameter x 24.6" Long
