Nortel 2332 - External Hardware Features

26 AP overview
NN47250-307 (324136-A Version 01.03)
External hardware features
Figure 1 and Figure 2 show the external hardware features of the Series 2332 access point.
Figure 1. AP Model —Top View
Figure 2. AP Model Series 2332 —Bottom View
840-9502-0040
Diameter
16.76 cm
(6.6 inches)
Height
6.10 cm
(2.4 inches)
External antenna
connectors
840-9502-0007
Unlock
RJ-45
port
Port 1
Kensington security
slot
802.11a
802.11b/g
Port 2
