36 Installing and connecting a Series 2332 Access Point
NN47250-302 (324136-A Version 01.03)
Figure 5 shows the universal mounting bracket.
Table 3: Required Mounting Hardware and Tools—
Series 2332 access point
Mounting Option Required Hardware and Tools
Included with the
Product
Suspended ceiling—flush ceiling
tiles
Mounting template Yes
Universal mounting bracket Yes
T-bar clamp
Note: A T-bar clamp is not required for a
23.9-mm (15/16-inch) T-bar ceiling with
flush ceiling tiles.
Yes
Box cutter No
Small screwdriver (3-mm or 1/8-inch) No
Suspended ceiling—drop ceiling
tiles
Mounting template Yes
Universal mounting bracket Yes
T-bar clamp Yes
Box cutter No
Small screwdriver (3-mm or 1/8-inch) No
Junction box Junction box No
Two #6-32 x 1-inch machine screws Yes
Universal mounting bracket Yes
Small screwdriver (3-mm or 1/8-inch) No
#2 Phillips-head screwdriver No
Solid wall or ceiling Two #6 sheet metal screws and two drywall
anchors
Yes
Universal mounting bracket Yes
Hammer No
Small screwdriver (3-mm or 1/8-inch) No
#2 Phillips-head screwdriver No
Note. A Series 2332 access point is plenum rated, so it can also be installed in the
space above the ceiling if preferred.
