External Antennas 65
Nortel WLAN Series 2332 Access Point Installation Guide
S4901790PN36RS DR4000090E6 5173 WLAN Directional Patch Panel Antenna with an
average gain of 15.7 dBi from 5.15 - 5.25 GHz,
15.9 dBi from 5.25 - 5.35 GHz, 16.0 dBi from
5.470 - 5.725 GHz and 15.8 dBi from
5.725 - 5.85 GHz. It has a 3-foot cable with a
Reverse SMA connector and either a tilt, wall or
pole mounting capability. Antenna is rugged, easy
to install and provides a very symmetrical and
uniform 90 degree H-plane and 5.5 degree E-plane
pattern. Designed for long, wide coverage
environments.
SR49120DAN36RS DR4000091E6 5103 WLAN Directional Patch Panel Antenna with an
average gain of 10.0 dBi from 5.15 - 5.25 GHz,
9.9 dBi from 5.25 - 5.35 GHz, 9.6 dBi from
5.470 - 5.725 GHz and 9.5 dBi from
5.725 - 5.85 GHz. It has a 3-foot cable with a
Reverse SMA connector and either a wall or pole
mounting capability. Antenna is rugged, easy to
install and provides a very symmetrical and
uniform 120 degree H-plane and 15 degree E-plane
pattern. Designed for long, wide coverage
environments.
2.4/5.0 GHz Dual Antennas
S24493DSN36RSM DR4000078E6 Mixed WLAN Dual-Band, Tri-Mode 802.11 a/b/g Spatial
Diversity Monopole Antenna. It operates over the
2.4 - 2.5 GHz and 4.90 - 5.875 GHz bands. It has
an average gain of 3.0 dBi from 2.4 - 2.5 GHz,
4.0 dBi from 4.90 - 5.15 GHz, 3.9 dBi from
5.15 - 5.25 GHz, 3.2 dBi from 5.25 - 5.35 GHz,
2.9 dBi from 5.470 - 5.725 GHz and 2.6 dBi from
5.725 - 5.85 GHz. It is equipped with a 3-foot cable
and a Reverse SMA connector. Each antenna port
can be used individually to support 802.11 b/g and
802.11a systems simultaneously for dual-band,
non-diversity applications. Optimal for use in high
data rate, high capacity configurations such as
enterprise offices.
