275
.
Appendix
External housing installation
Consult the work order, and perform the steps in this section as required:
•
Procedure 151 “Installing a C4710 basestation in an external housing”
(page 275)
•
“Installing a C4710E basestation in an external housing with an
external antenna” (page 278)
•
“Mounting the cabinet on a wall” (page 280)
•
“Mounting the cabinet on a pole” (page 281)
Installing a C4710 basestation in an external housing
Install a C4710 basestation in an external housing.
Procedure 151
Installing a C4710 basestation in an external housing
Step Action
1 Unlock the cabinet, and open the cabinet door.
2 Remove the foam cover and foam blocks from the cabinet.
3 Mount the swivel, and route the incoming cable through the
swivel.
4 Verify that the cable fits snugly into the waterproof inlet housing.
5 Connect the incoming cable to the connection box that is
delivered with the outdoor cabinet.
6 Connect the CAT5 cable that is inside the outdoor cabinet to the
connector box.
Nortel Communication Server 1000
SIP DECT Fundamentals
NN43120-123 02.02 30 March 2010
Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
.
