Nortel DMS-100 Series Product Guide

DPP Hardware 2-5
DPP Product Guide DPP001 and up
Figure 2-3
Data and Peripheral Interface connectors - Turbo DPPs
J1
J3
J11
J13
J14
J2
J9 J10
J4
J12
1
M
T
D
1
M
T
D
0
1
Not Used
MMI Link 1
MMI Link 2
EAT
(Emergency Administrative Terminal)
DSI0
(slot 13; A and B chassis)
DSI1
(slot 12; A and B chassis)
v.35 Link 1
(56K Baud maximum)
v.35 Link 2
(56K Baud maximum)
RS-232 Link 1
(9600 Baud maximum)
RS-232 Link 2
(9600 Baud maximum)
