Nortel DMS-100 Series Product Guide

DPP Hardware 2-7
DPP Product Guide DPP001 and up
Figure 2-5
Power, Ground and Alarm Interface connectors
12V AUX
+ CHAS -
FR
TB1
+12 FR LG
EXT ALMS
BATT BATT
-48 ALM RTN
TB2
TB3
12V
AC AC
8KHZ
CLOCK
DISK
DRIVE
J15
J16
J17
J18
FR
F1
DC Input Power
Alarms
Frame
Ground
+12V Fuse
Logic (Signal) Ground
+12V AUX
19 VAC Input
(60 HZ Clock - not supported in
systems with 3 1/2” disk drives)
(Terminal Block Chassis - no longer in production)
8KHZ
Clock (not
supported,
connector
removed)
J19
