DPP Hardware 2-3
DPP Product Guide DPP001 and up
Figure 2-2
DPP cabinet dimensions
19.00 in.
(482.6 mm)
FRONT VIEW
24.34 in.
(618 mm)
TOP VIEW
14.25 in.
(362 mm)
17.52 in.
(445 mm)
Shipping
Bracket
