Nortel DMS-100 Series Product Guide

DPP Hardware 2-9
DPP Product Guide DPP001 and up
Figure 2-6
DPP cabinet subassemblies
A1-----------------------A14
Processor A
Circuit Boards
B1------------------------B14
Processor B
Circuit Boards
Rover Interface
Panel
Processor B chassis
B21 Disk
Drive B
B20 Power
Supply
A21 Disk
Drive A
A20 Power
Supply
Processor A chassis
Switch and
Status Panel
FRONT VIEW (COVER OFF)
*Slots A7 and B7 are equipped if the DPP is a Turbo system
*
*
