Northstar FISH 457/467 Installation and Operation Manual 53
Setup and test
1 Put a blanking cap on any unused connector
on the back of the display unit. Ensure all
connectors are plugged in and the display
unit is in place.
2 If the display unit is bracket mounted, adjust
tilt and rotation for best viewing and hand
tighten the knob.
4 Turn the instrument on (see section 2-2).
When the 457/467 is turned on for the first
time, it displays an installation menu:
i Select the language to use.
ii Change the data if necessary (see section
2-1)
iii When the setup data is correct, press
.
9-1 Installation: Setup and test
This data can be changed later
(see section 8).
5 Enter setup data to set up the 457/467 to
your requirements and to set up any optional
sensors or instruments
(see section 8).
