NorthStar EXPLORER 457 - Page 55

Northstar FISH 457/467 Installation and Operation Manual 55
FISH 457
FISH 467
164.0 mm ( 6.5 ")
0.051
)" 9.5 ( mm
0.661
)"5.6 ( mm
)"
5 ( mm
7
2
1
88.5 mm ( 3.5 ")
32.0 mm ( 1.3 ")
33.1 mm ( 1.3 ")
195.0 mm ( 7.7 ")
0.971
)" 7 ( mm
0.591
)"7.7 ( mm
)
" 4.6 ( mm
361
88.5 mm ( 3.5 ")
19.5 mm ( 0.8 ")
35.2 mm ( 1.4 ")
