Operation Description
19
Right Rocker Switch Combination
Headlight Switch
Position “1”: The headlights are dimmed (low beams).
Position “0”: The headlights are off.
Position “2”: The high beams are on.
There are also headlight indicator lights on the instrument panel to indicate high/low beams.
Figure 2-13 Headlight Switch
Hazard Warning Switch
The hazard warning switch should be used in case of a tractor malfunction where the
tractor is stopped in a potentially dangerous area.
Position “1”: Flashers on
Position “0”: Flashers off.
Figure 2-14 Hazard Warning Switch
1 Headlight Switch
2 Hazard Warning Switch
Figure 2-12 Right Rocker Switch
Combinations
