Notifier ACPS-2406

Addressing Configuring the ACPS-2406
ACPS-2406 PN 51304:B 09/02/2003 19
Table 3.4 DIP Switch Settings Resulting in 8 Addresses Consumed
Table 3.5 DIP Switch Settings Resulting in 9 Addresses Consumed
Table 3.6 DIP Switch Settings Resulting in 12 Addresses Consumed
DIP
Switch
DIP Switch Setting
ACPS-2406 Addresses Selected
by DIP Switch Settings at Left
ACPS-2406 Addresses
SLC
Address
SW3.1 ON or OFF
✔ 1.Monitor General B*
SW3.2 ON or OFF
✔ 2. ACPS-2406 Output #1 B + 1
SW3.3 ON or OFF
✔ 3. ACPS-2406 Output #2 B + 2
SW3.4 ON or OFF
✔ 4. ACPS-2406 Output #3 B + 3
SW3.5
3.5 ON, 3.6 ON (Canadian Trouble
Reporting)
✔ 5. ACPS-2406 Output #4 B + 4
SW3.6 Not selected. 6. Signal Silence Address
SW3.7
Any combination except 3.7 ON, 3.8 OFF
(Dual Stage)
✔ 7. Monitor AC Fail (Canada only) B + 5
SW3.8
✔ 8. Monitor Battery (Canada only) B + 6
✔ 9. Monitor Earth Fault (Canada only) B + 7
SW2.1 ON or OFF
Not selected.
10. Dual Stage Output #1
SW2.2 ON or OFF 11. Dual Stage Output #2
SW2.3 ON or OFF 12. Dual Stage Output #3
SW2.4 ON or OFF 13. Dual Stage Output #4
SW2.5 OFF
Total: 8 Addresses
Assign 8 sequential SLC
addresses for this DIP Switch
configuration.
*B = SLC
Base
Address
SW2.6 ON or OFF
SW2.7 ON or OFF
SW2.8 ON or OFF
DIP
Switch
DIP Switch Setting
ACPS-2406 Addresses Selected
by DIP Switch Settings at Left
ACPS-2406 Addresses
SLC
Address
SW3.1 ON or OFF
✔ 1.Monitor General B*
SW3.2 ON or OFF
✔ 2. ACPS-2406 Output #1 B + 1
SW3.3 ON or OFF
✔ 3. ACPS-2406 Output #2 B + 2
SW3.4 ON or OFF
✔ 4. ACPS-2406 Output #3 B + 3
SW3.5
3.5 ON, 3.6 ON (Canadian Trouble
Reporting)
✔ 5. ACPS-2406 Output #4 B + 4
SW3.6
✔ 6. Signal Silence Address B + 5
SW3.7
Any combination except 3.7 ON, 3.8 OFF
(Dual Stage)
✔ 7. Monitor AC Fail (Canada only) B + 6
SW3.8
✔ 8. Monitor Battery (Canada only) B + 7
✔ 9. Monitor Earth Fault (Canada only) B + 8
SW2.1 ON or OFF
Not selected.
10. Dual Stage Output #1
SW2.2 ON or OFF 11. Dual Stage Output #2
SW2.3 ON or OFF 12. Dual Stage Output #3
SW2.4 ON or OFF 13. Dual Stage Output #4
SW2.5 ON
Total:9 Addresses
Assign 9 sequential SLC
addresses for this DIP Switch
configuration.
*B = SLC
Base
Address
SW2.6 ON or OFF
SW2.7 ON or OFF
SW2.8 ON or OFF
DIP
Switch
DIP Switch Setting
ACPS-2406 Addresses Selected
by DIP Switch Settings at Left
ACPS-2406 Addresses
SLC
Address
SW3.1 ON or OFF
✔ 1.Monitor General B*
SW3.2 ON or OFF
✔ 2. ACPS-2406 Output #1 B + 1
SW3.3 ON or OFF
✔ 3. ACPS-2406 Output #2 B + 2
SW3.4 ON or OFF
✔ 4. ACPS-2406 Output #3 B + 3
SW3.5
3.5 ON, 3.6 ON (Canadian Trouble
Reporting)
✔ 5. ACPS-2406 Output #4 B + 4
SW3.6 Not selected. 6. Signal Silence Address
SW3.7
3.7 ON, 3.8 OFF (Dual Stage)
✔ 7. Monitor AC Fail (Canada only) B + 5
SW3.8
✔ 8. Monitor Battery (Canada only) B + 6
✔ 9. Monitor Earth Fault (Canada only) B + 7
SW2.1 ON or OFF
✔ 10. Dual Stage Output #1 B + 8
SW2.2 ON or OFF
✔ 11. Dual Stage Output #2 B + 9
SW2.3 ON or OFF
✔ 12. Dual Stage Output #3 B + 10
SW2.4 ON or OFF
✔ 13. Dual Stage Output #4 B + 11
SW2.5 OFF
Total:12 Addresses
Assign 12 sequential SLC
addresses for this DIP Switch
configuration.
*B = SLC
Base
Address
SW2.6 ON or OFF
SW2.7 ON or OFF
SW2.8 ON or OFF
