Notifier FDU-80

FDU-80 Annunciator
SW1 DIP Switch Settings
11
Document 51264 Rev A2 6/14/00 P/N 51264:A2
4 through 6 = Configuration for use with a particular FACP.
Switches 4, 5 and 6 are used to select the FACP (Fire Alarm Control
Panel) which is being connected to the FDU-80. Refer to the
following table for the appropriate switch settings.
7 and 8 = Future use.
Fire Alarm Control Panel SW1-4 SW1-5 SW1-6
AFC-600 (all releases)
AFP300/400 (with FACP
software Version 3.62 or higher)
OFF OFF OFF
Future Use OFF OFF ON
Future Use OFF ON OFF
Future Use OFF ON ON
Future Use ON ON OFF
Future Use ON OFF ON
Future Use ON ON OFF
Future Use ON ON ON
