NFS-320/E/C, NFS-320SYS/E Operations Manual —
P/N 52747:E1 06/16/2011
67
Using the CRT-2 for Alter Status
Remote Terminal Access
C.4.7 Set the Pre-Alarm for Alert o
r Action
Set Action/Alert lets you set the Pre-alarm for Al
ert or
Ac
tion. For exam
ple, change Pre-alarm
from “Alert” to “A
ction” as fo
llows:
Set Pre-alar
m Alert (NO)/Action(
YES). Type N or Y then Ente
r
STATUS CHANGE Change
Alert/Acti
on
08:29A Tue 01/15/
08
Press <
5
><
ENTER
>
Pre-alarm no
w set for ACTION
Press <
Y
><
ENTER
>
66
68
Table of Contents
Default Chapter
2
Fire Alarm System Limitations
2
Installation Precautions
3
Table of Contents
5
Section 1: General Information
8
UL 864 Compliance
8
About this Manual
8
1: Cautions and Warnings
8
2: Typographic Conventions
8
3: Supplemental Information
9
4: Shortcuts to Operating Functions
10
Introduction to the Control Panel
10
Section 2: Use of the Controls
11
Introduction
11
System Status Indicator Leds
11
Control Keys
12
1: Acknowledge/Scroll Display
12
2: Signal Silence
13
3: System Reset
13
4: Drill
14
5: Lamp Test
14
Programming Keypad
14
Section 3: Operation of the Control Panel
16
Overview
16
Normal Mode of Operation
16
Fire Alarm Mode of Operation
17
1: How the Control Panel Indicates a Fire Alarm
17
2: How to Respond to a Fire Alarm
17
3: Interpreting Fire Alarm Type Codes
18
Carbon Monoxide (CO) Alarm Mode of Operation
20
1: How the Control Panel Indicates a CO Alarm
20
2: How to Respond to a CO Alarm
20
3: Interpreting CO Alarm/Supervisory Type ID Codes
21
System Trouble Mode of Operation
21
1: How the Control Panel Indicates a System Trouble
21
2: How to Respond to a System Trouble
22
Security Alarm Mode of Operation
23
1: How the Control Panel Indicates a Security Alarm
23
2: How to Respond to a Security Alarm
23
System Trouble Mode of Operation
23
3: Interpreting Security Type Codes
24
Active Supervisory Signal Mode of Operation
24
1: How the Control Panel Indicates an Active Supervisory
24
2: How to Respond to an Active Supervisory
25
3: How to Interpret Supervisory Type Codes
25
Pre-Alarm Warning Mode of Operation
26
1: How the Control Panel Indicates a Pre-Alarm Warning
26
2: How to Respond to a Pre-Alarm Warning
27
Disabled Points Mode of Operation
28
Non-Alarm Mode of Operation
28
1: Purpose of Non-Alarm Points
28
2: How the Control Panel Indicates an Active Fire Control
29
3: How the Control Panel Indicates an Active Non-Fire Point
29
Active Trouble Monitor Mode of Operation
29
1: How the Control Panel Indicates an Active Trouble Monitor
29
2: How to Respond to an Active Trouble Monitor
30
Output Circuit Trouble Mode of Operation
30
1: Overview
30
2: How the Control Panel Indicates a NAC Trouble
31
3: How the Control Panel Indicates a Control/Relay Trouble
31
4: How to Respond to a NAC or Control/Relay Trouble
32
Operation of Special System Timers
32
1: What Are System Timers
32
2: How to View System Timer Selections
32
3: How System Timers Work
32
Waterflow Circuit Operation
33
Style 6 and Style 7 Operation
33
Section 4: Read Status Operation
34
Introduction
34
What Is Read Status
34
1: Quick Reference Key Sequences
34
Entering Read Status
34
Viewing and Printing a Read Status
35
1: How to View Read Status of Devices, Zones, & System Settings
35
2: How to View Read Status for Event and Alarm History
44
3: How to Print Points, Event and Alarm History
45
4: How to View and Print Hidden Event and Alarm History
47
Appendix A, "Special Zone Operation
49
A.1: Overview
49
A.2: Releasing Zones (R0-R9)
49
A.2.1: Purpose of Releasing Zones
49
A.2.2: How to View Releasing Zone Selections
50
A.2.3: How Releasing Zones Operate
50
A.3: Time, Date, and Holiday Functions
52
A.3.1: Overview
52
A.3.2: How to View Time Control Selections
52
A.3.3: How to View Holiday Function Selections
53
A.3.4: How Time Control and Holiday Functions Work
53
A.4: NAC Coding
54
A.4.1: Overview of Coding
54
A.4.2: How to View Coding (F8) Selections
54
A.4.3: How to Respond to an Alarm with Coding
55
A.5: Presignal and Positive Alarm Sequence (PAS) Operation
55
A.5.1: Overview
55
A.5.2: What Is Presignal and PAS
55
A.5.3: How to View Presignal and PAS Selections
56
A.5.4: How to Respond to an Alarm with Presignal Delay Timer (no PAS)
56
A.5.5: How to Respond to an Alarm with Presignal Delay Timer (PAS Selected)
57
Appendix A: Special Zone Operation
49
Appendix B, "Intelligent Detector Functions
58
Appendix B: Intelligent Detector Functions
58
Appendix C: Remote Terminal Access
60
C.1: General Description
60
C.2: Operating Modes
60
C.2.1: Local Terminal Mode (Loct)
60
C.2.2: Local Monitor Mode (Locm)
61
C.2.3: Remote Terminal Mode (Remt)
61
C.3: Using the CRT-2 for Read Status
62
C.3.1: Overview
62
C.3.2: Accessing Read Status Options
62
Appendix C.3, "Remote Terminal Mode Functions
62
C.3.3: Read Point
63
C.3.4: Display Devices in Alarm or Trouble
63
C.3.5: Display All Programmed Points
64
C.3.6: Step-Through History
64
C.3.7: View All History
64
C.3.8: Step-Through Alarm History
64
C.3.9: View All Alarm History
64
C.4: Using the CRT-2 for Alter Status
64
C.4.1: Overview
64
C.4.2: Accessing Alter Status Options
65
C.4.3: Enable or Disable Detectors, Modules or Zones
65
C.4.4: Change Alarm and Pre-Alarm Levels
66
C.4.5: Clear Verification Counter
66
C.4.6: Clear the Entire History Buffer
66
C.4.7: Set the Pre-Alarm for Alert or Action
67
Appendix D: Point and System Troubles Lists
68
Appendix D, "Point and System Troubles Lists
68
D.1: Point (Device) Troubles
68
D.2: System Troubles
69
