SPECIFICATIONS
Due to continued product improvement, this specication may change without notice.
GENERAL
Operating voltage for power supply unit 220 V - 240 V AC 1.3 A
Power consumption 12 W (max)
Dimensions (W x D x H) 275.16 mm x 159.6 mm x 40 mm
Weight 1.765 kg (packed, including accessories)
Operating temperature range 0 °C to +50 °C
Storage temperature range –20 °C to +60 °C
REARPANEL CONNECTORS
DC POWER 12 V DC 3.3 A
SAT IN 1 F-type female
AUDIO L and R 2 x phono audio-out sockets
VIDEO OUT Phono composite video-out socket
DIGITAL AUDIO OUT Coaxial S/PDIF connector (female)
TV SCART SCART (composite video out; RGB out; audio L and R out)
HDMI HDMI
USB 2.0 Host Port (Type A) (for future use)
ETHERNET RJ45 female (for future use)
RF IN IEC 60169-24 F-type female
RF OUT IEC 60169-24 F-type female
FRONTPANEL CONNECTOR
Smartcard slot
