16
ML0042 October 15, 2019 Copyright 2019 Bitronics, LLC
Input Signals – Measurement Inputs
Range 0 to 150V rms
System Voltage Intended for use on nominal system voltages up to 208 V rms,
phase-to-phase
120V rms, phase-to-neutral
.
Common Mode
Input Volta
e
Reads to 400V peak, any input-to-case (ground)
Impedance >12M ohms, input-to-case (ground)
Voltage
Withstand
2.5kV rms 1min, input-to-case (ground)
2kV rms 1min, input-to-input
Frequency 45-65 Hz
Sampling System
Sample Rate 64 samples per cycle
Data Update Rate Amps, Volts Available every 100 ms
Watts, VAs, VARs,
PF
Available every 100 ms
Number of Bits 16
