17
ML0042 October 15, 2019 Copyright 2019 Bitronics, LLC
Communication Ports
Ethernet Single port; copper 10/100 Base-TX (standard)
Single port; LC fiber 100 Base-FX (option)
Serial (option) RS-232, RS-485, Software configurable ports
Baud rate: 9600 bps to 115.2 kbps
Environmental
Operating Temperature -40C to 70C
Accuracy
Accuracies are specified at nominal Frequency and 25C, (unless otherwise noted). Unless noted, all values are true RMS
and include Harmonics to the 31st
minimum
.
Voltage AC: Better than 0.1% of reading (20 to 150 V rms, input-to-case). (+/-
25ppm/De
C
Voltage Aux Only included with
meters manufactured
with the monitoring
option
AC/DC: Better than 1.0% of reading
Current Input option 1 (Internal
Isolation - 1A ac)
Better than 0.1% of reading +/- 20uA (>0.1A to 2.0A, -20C to 70C)
Better than 0.1% of reading +/- 50uA (0.01A to 0.1A, -20C to 70C)
Minimum reading 1mA
Input option 5 (Internal
Isolation - 5A ac)
Better than 0.1% of reading +/- 100uA (>0.5A to 10.0A, -20C to 70C)
Better than 0.1% of reading +/- 250uA (0.05A to 0.5A, -20C to 70C)
Minimum reading 5mA
Input Option T Better than 0.1% of reading +/- 100uA (>1.0A to 10.0A, -20C to 70C)
Better than 0.1% of reading +/- 2mA (0.05A to 1.0A, -20C to 70C)
Minimum reading 10mA
Frequency +/- 0.001 Hertz
Power Meets or exceeds IEC 62053-22, -23, 0.2S
