10
22 Capture
MIDI
Capture any recently played MIDI notes in your
DAW (supported by Live, Cubase and Logic).
23 Quantise Triggers the quantise function in Live, Cubase and
Logic, to snap notes to the grid.
24 Click Toggles Logic, Cubase and Live’s metronome on and off.
25 Undo Triggers Logic, Cubase and Live’s undo function.
26 Play, Record, Stop, Loop Controls the transport in your DAW.
22
26
23 24 25
Getting Connected
Connecting Launchkey with a Computer
Your Launchkey is USB bus-powered, it’s powered when you connect it to your computer with a USB
cable. When connecting Launchkey for the first time, visit Components to make sure you have the
latest firmware. This will make sure you have all the latest features enabled.
Power and MIDI via USB
USB Cable
Note: When connecting Launchkey to a Mac you may see the Keyboard Setup Assistant. This is
because Launchkey functions as a computer keyboard device in Navigate Mode. Please close the
Keyboard Setup Assistant.
Connecting Launchkey with External MIDI Enabled Instruments
If you want to use the 5-pin DIN socket for MIDI output on your Launchkey without a computer, you
can power the unit with a standard USB power supply (5V DC, minimum 500mA).
MIDI Device/Sound
Module
USB
Power
MIDI Cable
