Overview
Main Unit: Front
1 2 3 4 5 6 7
8 9 10 11 12 13 14 15 16 17 18
1 Power On/Standby button
2 Remote control IR receiver
3 3.2” TFT colour display
4 CD player slot
5 Back button
6 Reel: Navigate; Ok/Select
7 Reel: Volume; short press to mute
8 USB port for music playback
9 Earphone jack
10 Previous/Rewind; Preset 1
11 Play/Pause; Preset 2
12 NEXT/FAST FORWARD; Preset 3
13 STOP
14 FAV button
15 Alarm button
16 Mode button
17 Menu/Info button
18 Eject
Main Unit: Back
19 20
21 22 23 24 25 26
19 DAB+/FM Antenna
20 WiFi/BT Antenna
21 OPTICAL Out socket
22 COAXIAL Out socket
23 RCA LINE Out-R socket
24 RCA LINE Out-L socket
25 LAN Port
26 DC In power supply
