MECHANICAL INSTALLATION
NPK MOUNTING INSTALLATION KITS include the parts required to adapt the NPK
Sheet Pile Driver to the stick or arm of the carrier. Custom adapter brackets and quick
attach brackets are available. Shown below is a typical NPK mounting kit. Mounting
kits are machine specific. Contact the NPK Sales Department for additional information.
See the FASTENER TORQUE section of the NPK Instruction Manual for top bracket
bolt torque.
HYDRAULIC HOSE ASSEMBLY (pressure)
HYDRAULIC HOSE ASSEMBLY (return)
When mounting or removing the Sheet Pile Driver from the
carrier, the hydraulic lines must be handled carefully and
sealed to prevent contamination from entering the
compactor or the carrier hydraulic system.
