NPK C6CSD - Specifications

NPK
- 8 -
SPECIFICATIONS
MODEL
CYCLES
OIL FLOW
OIL FLOW
OIL FLOW
PER
(standard)
(low flow option)
(high flow option)
MINUTE
gpm
(lpm)
gpm
(lpm)
gpm
(lpm)
C6CSD
2,200
33
(125)
25.5
(97)
N/A
C8CSD
2,200
43
(160)
CONTACT NPK
N/A
C10CSD
2,200
51
(210)
CONTACT NPK
N/A
MODEL
IMPULSE
OPERATING
RELIEF VALVE
FORCE
PRESSURE₁
PRESSURE SETTING
2
lbf
(kgf)
psi
(bar)
psi
(bar)
C6CSD*
16,000
(7,300)
1800-2300
(125-160)
2600
(180)
C8CSD*
24,000
(11,000)
2000-2500
(140-170)
2600
(180)
C10CSD*
34,000
(15,450)
2000-2500
(140-170)
2600
(180)
* The carrier circuit relief valve settings should be a minimum of 200psi (14 bar) above the sheet driver
relief settings.
1. Operating pressures shown are with a standard hydraulic motor. Operating pressures will be different
with optional hydraulic motors.
2. Relief pressure setting shown is for a standard hydraulic motor. For a relief with different motor options,
contact NPK at 1-800-225-4379.
(Specifications subject to change without notice.)
MODEL
CHUCK CYLINDER
CHUCK CYLINDER
OIL FLOW
OP. PRESSURE
gpm
(lpm)
psi
(bar)
C6CSD
3 - 5
(11 - 20)
3045
(210)
C8CSD
3 - 5
(11 - 20)
3045
(210)
C10CSD
3 - 5
(11 - 20)
3045
(210)
