2. DISASSEMBLY PROCEDURE

Caution

Disassemble on a tray to prevent losing parts.

In case of EC-30

2-1 Removal of Sheath

Protect the Sheath and the Elbow Ass’y with Emery Cloth, turn counterclockwise with T-2 to remove the Sheath.

Elbow Ass’y

Drive Shaft Ass’y

Sheath
