Tx I&O Manual │General Venting
17
Termination Options – Direct Vent Installation
The venting system of the Tx may be terminated using field supplied piping to construct a “Two-Pipe”
termination, see Figures 4-3a, 4-4a, 4-4d, 4-5a, 4-6a and 4-6d; alternatively the venting may be terminated using
a factory kit selected from Table 4-4.
Venting Options - Due to potential moisture loading (build-up) along the exterior wall,
sidewall venting may not be the preferred venting option (see Figures 4-4 and 4-6).
Optional Termination Kits – Direct Vent Installation
Kits certified with the Trinity Tx are listed in Table 4-4 and available from IPEX, DuraVent, Centrotherm and/or
NTI. For more information on System 636 Vent Kits or wholesaler locations contact IPEX directly USA: 1-800-
463-9572 or www.IPEXamerica.com │ CAN: 1-866-473-9462 or www.ipexinc.com. For more information on
PolyPro Vent Kits or wholesaler locations contact DuraVent directly 1-800-835-4429 or www.duravent.com. For
more information on InnoFlue Vent Kits or wholesaler locations contact Centrotherm directly at 1-877-434-3432
or www.centrotherm.us.com.
Table 4-4 Optional Vent Termination Kits
Description
Vent
Size
Supplier P/N
Figure
Vent Material
Compatibility
Vent Option
Roof
Wall
IPEX Low Profile
(Flush Mount)
7
2”
196984
4-3(b), 4-5(c)
PVC/CPVC
7


3”
196985 (NTI P/N 84357)
IPEX Concentric
(Wall/Roof)
5,6,7
2”
196005
4-3(c), 4-4(c),
4-5(b), 4-6(b)


3”
196116 (NTI P/N 82666)
197009
DuraVent - PolyPro
Concentric (Wall)
2”
2PPS-HK
4-3(c), 4-5(d)
PVC/CPVC/PPs


3”
3PPS-HK
DuraVent - PolyPro
Concentric (Roof)
2”
2PPS-VK
4-4(c), 4-6(c)


3”
3PPS-VK
Centrotherm – InnoFlue
(Flush Mount)
2”
ISLPT0202
4-3(b), 4-5(c)


3”
ISLPT0303
Centrotherm – InnoFlue
Concentric (Wall)
8
2”
ICWS2413 & ICTC0224
4-3(c), 4-5(d)


3”
ICWS3513 & ICTC0335
ICWT352 & ICTC0335
Centrotherm – InnoFlue
Concentric (Roof)
8
2”
ICRT2439 & ICTC0224
4-4(c), 4-6(c)


3”
ICRT3539 & ICTC0335
Notes:
1
Instructions included with termination kits contain detailed assembly and installation instructions.
2
All factory termination kits are ULC S636 approved.
3
Clearance requirements in this manual supersede those of the instructions included with the vent terminal.
4
Piping MUST be secured to the vent terminal during installation.
5
IPEX Concentric Terminal MUST be cemented together and to the vent pipes during installation.
6
Vent Screens provided with boiler may be used with the IPEX Concentric Vent Kits; otherwise use IPEX vent screens
(2” vent screen P/N 196050; 3" vent screen P/N 196051 – each sold separately).
7
IPEX Low Profile and Concentric kits (excluding P/N 197009) are constructed out of ULC S636 approved PVC; check
with your local authority for the acceptance of PVC as a venting material prior to use.
8
Centrotherm Concentric termination kits must use the applicable “Twin pipe to concentric adapter”, part number
ICTC0224 or ICTC0336.
