NTI Trinity TX101 - Tx Controls View; Electrical Housing, Controller, and Display Module View; Tx Installation Kit Box View

Tx I&O Manual │ Parts List
79
Figure 19-1(d) Tx Controls
Electrical Housing, Controller, and Display Module
Figure 19-1(e) Tx Installation Kit Box
Table 19-1 Parts List: Tx Series
Item
Part #
Description
1
84882
Burner Assembly, c/w door, insulation & gasket (Tx51)
1
84883
Burner Assembly, c/w door, insulation & gasket (Tx81)
1
84884
Burner Assembly, c/w door, insulation & gasket (Tx101)
1
84885
Burner Assembly, c/w door, insulation & gasket (Tx151 & Tx151C)
1
85056
Burner Assembly, c/w door, insulation & gasket (Tx200 & Tx200C)
2
84743
Flue Outlet Gasket (all Tx models)
3
84597
Blower Mounting Screws, M5x12 Hex (all Tx models)
70
70
70
52
23
61
107
74
There are 5 different Tx Conversion Kits.
Each kit has the required orifice,
decal and instructions.
113
112
8
Natural Gas to LP Conversion Kit
119
Common
(All Tx Models)
38
80
59
110
38
109
71
117
Heat Only
(Tx51-200)
Combi Only
(Tx151C & Tx200C)
115
110
114
80
116
111
