Part 9 - Controls
Menu
Sub-Menu
Parameter
Description Value
Default
Setting
Note
42 BMS
42. 0 GENERAL
42. 0. 0 BMS Control Mode Disabled
Voltage Power
Voltage Temp
Current Power
Current Temp
External Controller
Power
External Controller
Temp
42. 0. 1 BMS Max Temp
42. 0. 2 BMS Min Temp
42. 0. 3 Gateway modbus
address
42. 1 ANALOG LEVEL SETTINGS
42. 1. 0 BMS Analog Control Voltage to Start Heat Demand
42. 1. 1 BMS Analog Control Voltage to Stop Heat Demand
42. 1. 2 BMS Analog Control Voltage for Maximum Heat Demand
42. 1. 3 BMS Analog Control Voltage for Minimum Heat Demand
42. 1. 4 BMS Analog Control Current to Start Heat Demand
42. 1. 5 BMS Analog Control Current to Stop Heat Demand
42. 1. 6 BMS Analog Control Current for Maximum Heat Demand
42. 1. 7 BMS Analog Control Current for Minimum Heat Demand
42. 2 DIAGNOSTICS
42. 2. 0 Status Absent
Disabled
OFF
Standby
Heat Request
Config Error
Voltage input configuration error
Current input configuration error
External input configuration error
42. 2. 1 BMS Level
42. 2. 2 BMS SetPoint
42. 2. 3 BMS Input Voltage
42. 2. 4 BMS Input Current
Table 40 - Tech Menu - PCB Replacement Parameters List
To navigate the PCB Replacement Menu proceed as follows:
1. From the Tech Menu, turn the dial to highlight “PCB Replacement”
and press ENTER.
2. Turn the dial to select the parameters and press ENTER.
4. Modify the setting by turning the dial, press ENTER to save the value.
Note: pressing ESC exits the screen without saving the new value.
5. Press ESC to return to the previous screen.
7. PCB Replacement
Tech Menu
Cascade Setup
Restore/Backup
BMS Control
Complete Menu
PCB Replacement
2.1.9 Flow Sensor Type
2.2.0 Ignition Power
2.2.9
Set boiler heating power
xxx
xxx
xxx
xxx
xxx
PCB Replacement
2.1.2
3-way Valve Anti-Noise Function
2.2.8
Boiler version
Tech Menu
Cascade Setup
Restore/Backup
BMS Control
Complete Menu
PCB Replacement
2.1.9 Flow Sensor Type
2.2.0 Ignition Power
2.2.9
Set boiler heating power
xxx
xxx
xxx
xxx
xxx
PCB Replacement
2.1.2
3-way Valve Anti-Noise Function
2.2.8
Boiler version
Parameter Description
2.1.2 3-way Valve Anti-Noise Function
2.1.9 Flow Sensor Type
2.2.0 Ignition Power
2.2.8 Boiler version
2.2.9 Set boiler heating power
2.3.2 Max DHW percentage
2.3.3 Min percentage
2.3.4 Max CH percentage
2.4.3 CH Fan Post-Purge
2.5.4 DHW Post Purge and Pump Cycle
Modify the parameters as indicated in the instruction sheet of the
Main board replacement Kit.
WARNING
Figure 98 - Tech Menu
PCB Replacement
