Revision 2.2
Specifications 3-3
Table 3-1. ChannelMaster TX1 Specifications
(Continued)
Physical Characteristics:
Size (Low Pwr Unit): ............................... 4.89" (12.42 cm) x 7.5" (19.05 cm) x 12.0"
(30.48 cm)
Size (Hi Pwr Unit): ................................... 5.2" (13.21 cm) x 7.5" (19.05 cm) x 12.0"
(30.48 cm)
Weight:
Single-Band (2 GHz), Low-Power:..... 15.25 lbs (6.86 kg)
Duale-Band (2/7 GHz), Low-Power: .. 16.50 lbs (7.43 kg)
Single-Band (2 GHz), High-Power:.... 15.75 lbs (7.09 kg)
Duale-Band (2/7 GHz), High-Power:.. 17.00 lbs (7.65 kg)
Connectors:
Video / SDI / DVB-ASI / 70MHz IF: ........ Type BNC-F
RF Output: ............................................... Type “N-F” RF Head
Audio: ...................................................... Multi-pin, Detoronics DT02H-14-15PN
(XLR break-out cable provided)
Power: ..................................................... Multi-pin MS Type, Detoronics DT02H-14-18PN
(XLR break-out cable provided)
Remote Control: ...................................... 9 Pin “D” Female
Case:
Ruggedized to withstand rough handling in the field with handles that protect controls
from damage. Case is weather-resistant and all connectors are weatherproofed.
