CHANNEL / FREQUENCY PLAN - CHART NO: 10
(Frequency Range 12,706MHz - 12,950MHz)
Channel Offset Receive Frequency MHz
1 -
12,706.25
1 0
12,712.50
1 +
12,718.75
1 ++
12,725.00
2 -
12,731.25
2 0
12,737.50
2 +
12,743.75
2 ++
12,750.00
3 -
12,756.25
3 0
12,762.50
3 +
12,768.75
3 ++
12,775.00
4 -
12,781.25
4 0
12,787.50
4 +
12,793.75
4 ++
12,800.00
5 -
12,806.25
5 0
12,812.50
5 +
12,818.75
5 ++
12,825.00
6 -
12,831.25
6 0
12,837.50
6 +
12,843.75
6 ++
12,850.00
7 -
12,856.25
7 0
12,862.50
7 +
12,868.75
7 ++
12,875.00
8 -
12,881.25
8 0
12,887.50
8 +
12,893.75
8 ++
12,900.00
9 -
12,906.25
9 0
12,912.50
9 +
12,918.75
9 ++
12,925.00
10 -
12,931.25
10 0
12,937.50
10 +
12,943.75
10 ++
12,950.00
Table 3-5: Frequency Plan (US), 12GHz
