FRONT PANEL OVERVIEW
1
2
5
3
4
1. CD/DVD Drive – Insert CD/DVD discs into this drive. You can play audio CDs as well as data CD and DVD
discs, as long as the music files are in one of the compatible file formats.
2. Eject– This button opens and closes the CD/DVD drive tray. Please note that you cannot eject the tray if
actively playing back or cueing music from the drive.
3. Hard Drive – The unit’s hard drive holds your personal music collection, which is ready to use as soon as the
HDMIX is powered on. When connected to a computer, this hard drive will show up as an external drive,
allowing you to transfer music and build a Library directly from your computer.
4. Lock – Use the included key to lock and unlock the hard drive from its enclosure. Please note that the hard
drive needs to be in and locked for the hard drive to function.
5. Headphone Outputs (1/4” or 1/8”) – Connect your 1/4” or 1/8” headphones to these outputs.
