Floor Tool Overview

1. Retaining knobs x 2

2. Front blade (Slotted / Reversible)

3. Blade carrier

4. Rear blade

5. Floor tool main body

NOTE: The blades are designed to be

reversible and rotated giving 4 usable

surfaces (front, back, top and bottom, thus

extending their useful working life).

To change the oor-tool, rstly lower the

oor-tool using the left side oor-tool

lowering foot pedal (A).

Pull the oor-tool away from the machine (B).

Ret the blade holder, retain using the two outer knobs. Make

sure the slotted blade goes to the front of the oor-tool.

Ret the oor-tool using the two central knobs to the oor-tool.

Make sure the end holes on both squeegee blades are posi-

tioned correctly on ‘T’ shaped clip mouldings! (A)

Replace the Squeegee blades using

replacement blade set (Fig.3), tting the

blades on to the moulded location lugs.

Remove the blade holder (2).Unscrew the two knobs securing the blade

holder (1).

Changing the Floor Tool Blades

ALWAYS MAKE SURE THAT THE MACHINE IS SWITCHED OFF AND THE BATTERY IS

REMOVED PRIOR TO ANY MAINTENANCE.

Retting the oor tool blades
