Numatic TTB 6055 - Control Panel Overview

6
3
4
6
8
Control Panel Overview
For full easy to follow instructions on control panel set up and use, see machine operation page 30 & 32.
1 Control Handle (Start / Stop Trigger) 6 Mode Display Panel
2 Main Control On / Off Key 7 Off-aisle Vacuum Button
3 Water Flow Rate Adjustment 8 Battery Charge Level Meter
4 Hi - Lo Button 9 Hour Meter Toggle Button
5 Recovery Tank ‘Full’ Indicator 10 Brush Operation / Load Indicator
5
2
1
7
9
10
