Filling the clean water tank
The TTV-4555 is equipped with a large capacity 60 litre clean-water tank allowing, for large areas to be covered in
a single ll.
To ll the clean-water tank, extend the hose located to the rear of the machine in the centre of the removable ller cap,
(Fig 17). Pull out hose, (Fig 18). Open the stopper (Fig 19) and place hose under water tap, or use a hose to
commence lling (Fig 20).
Or the tank can be lled by unscrewing the ller cap and using a bucket or similar container (Fig 21).
Note: Great care must be taken to ensure that contaminants (leaves, hair, dirt, etc.) are not allowed to enter the
clean-water tank during the lling process. If using a bucket or similar, ensure it is always clean and free from debris.
Fig.20
Fig 17
Fig.19
Fig 18
Fig.21
The water level in the
clean water tank can
be measured using the
scale on the left rear
side of the machine
(Fig 22).
The clean water
bottom tank holds 60
litres.
Fig 22
Fill-level indicator
