15
Set automatic Chemical Dosing Mix as required, depending on oor type and level of soiling.
Set desired traction Speed as required, depending on
oor type and level of soiling.
Middle speed is the optimum cleaning speed.
Once the Max speed has been set using the knob on the
control panel, ne adjustments can be made using the
variable control speed trigger.
Set Water Flow Rate as required, depending on oor type and level of soiling
Insert the key into the master control on/off and quarter-turn it clockwise to the ‘ON’ position.
The battery charge-level indicator will illuminate for 5 seconds.
0.13 gal / min
0.26 gal / min
0.52 gal / min
0.79 gal / min
100:1 75:1 50:1 25:1
100 : 1
75 : 1
50 : 1
25 : 1
The TTV-4555 has been tted with a Hi - Lo mode, this reduces the noise produced by
the vacuum motor by 3dB.
To operate the Hi - Lo mode start the machine in the normal way.
When the machine is running normally the Hi - Lo light will NOT be
illuminated This means the Vacuum motor is running at 100%.
With the machine running press the Hi - Lo button once the Vacuum motor will reduce
speed to 75% of capacity and the Hi - Lo light will illuminate Blue.
Setting the Cleaning Controls
